hepatocyte in liver (monkey)
(for unlabelled original image click here, please!)

Cmv = Corpusculum multivesiculare (multivesikuläres Körperchen); Ec = Euchromatin;
Ef = Endothelocytus fenestratus (gefensterte Endothelzelle = Sinusoidendothel);
Grg = Granulae glycogeni (Glykogengranula); Hc = Heterochromatin; Ko = Kollagenfaserbündel
(hierbei handelt es sich um Kollagen Typ3, also reticuläre Fasern, die im Disse-Raum verlaufen);
L = Lumen (Lebersinusoid = Kapillare der Leber; mündet in die Vena centralis);
Ma = Macula adhaerens (Fleckdesmosom); Mi = Mitochondrium (Crista-Typ);
Mn = Membrana nuclearis (Kernmembran); Mv = Mikrovilli des Hepatocyten;
N = Nucleus (Zellkern); Nc = Nucleolus (Kernkörperchen); Px = Peroxysom;
RER = rauhes endoplasmatisches Retikulum; S = Spatium intercellulare (Zwischenzellraum);
Sp = Spatium perisinusoideum (Disse-Raum; liegt zwischen Leberzellen und dem Sinusoidendothel);
Vc = Vas capillare (Gallenkapillare); Vs = Vesiculum secreti (Sekretvesikel);
Za = Zonula adhaerens (Gürteldesmosom); * = Fenestrae (offene Stellen im Ef).
