A-band from skeletal musculature in longitudinal section (monkey)
(for unlabelled original image click here, please!)

A = anisotrope (doppelbrechende Bande (A-Bande, Länge entspricht der Länge der Myosinfilamente);
Grg = Beta-Glykogengranula; H = Hensenscher (heller) Streifen; I = isotrope Bande (i-Bande wird bei Kontraktion kürzer);
M = M-Streifen (Verbindungen von Myosinfilamenten); Mi = Mitochondrium (Crista-Typ);
SER = sarkoplasmatisches Retikulum (glattes endoplasmatisches Retikulum, speichert Ca++).
